SANY Length&Angle Sensor/ Length&Angle Sensor for SANY Crane
Used for SANY crane:
STC120C,STC160C, STC200,STC200S,STC200C5,STC250,STC250H,STC250S,STC500,
STC500C,STC500S,STC750,STC750S，STC900, STC1000, STC1000C, STC1250, STC2200
STC250T, STC350T, STC550T, STC800T6, STC1000T；
SAC12000, SAC6000, SAC3500, SAC3000, SAC2600, SAC2200C, SAC2200, SAC1800；
SRC750, SRC550C, SRC350
Other SANY crane spare parts are also available ,
| SR No. | Part No. | Chinese Description | English Description |
| 1 | 60023928 | TG油封150×134.5×6.3（中心回转接头密封） | oil seal |
| 2 | 10884426 | 水平油缸总成ZXQY52.47DQ521D工艺密封件包 | Q521Dprocess sealer package |
| 3 | 10071378 | 前垂直油缸ZXSYM5421JA.3.8Q500A工艺密封件包 | Q500A sealing element package |
| 4 | 10072207 | 后垂直油缸ZXSYM5421JA.3.9Q502A工艺密封件包 | Q502A sealing element package |
| 5 | 11779159 | 第五支腿油缸ZXQY25C.50AQ255B工艺密封件包 | Q255B PROCESS Package for sealing part |
| 6 | 10071379 | 变幅油缸ZXQY50C.2.4Q503A工艺密封件包 | Q503A sealing element package |
| 7 | 10059280 | 伸缩油缸ⅠZXSTC600.1.7.1504A工艺密封件包 | Q504A sealing element package |
| 8 | 11952989 | 伸缩油缸ⅡZXSTC600.1.7.2Q608工艺密封件包 | Q608 sealer package |
| 9 | 60059726 | （伸缩）电磁换向阀DS3-TA/10V-D24K | Unloading electromagnetic valve |
| 10 | 60164420 | 减压阀PRMP064-EN-1-0 | Reducing Valve |
| 11 | 60211890 | 溢流阀CP210-1-B-0-E-C-075 | Relief Valve |
| 12 | A229900002305 | 蓄能器NXQ-L0.63/10-A | Accumulator |
| 13 | B220401000041 | 梭阀DSV1-10-B-O | Shuttle valve |
| 14 | B220401000045 | 单向阀CV1-10-P-O-30 | Check Valve-CV1-10-P-O-30 |
| 15 | A820606010828 | 空压机进气胶管 | Air compressor air intake rubber pipe |
| 16 | 11878625 | 空滤器出气胶管SYM5334J1.1.3-4 | Air filter air-outlet rubber pipe |
| 17 | 11877415 | 增压器进气胶管SYM5334J1.1.3-2 | Air inlet hose for turbocharger |
| 18 | 11296830 | 橡胶管（进气） | Rubber hose |
| 19 | 11904670 | 进水胶管ⅠSYM5425J3.1.5-2（弯） | Water inlet hose |
| 20 | 11014544 | 发动机进水胶管SYM5428J.1.5-3 | engine Water inlet hose |
| 21 | 11302756 | 发动机出水胶管SYM5428J3.1.5-2 | Water outlet rubber tube of engine SYM54 |
| 22 | 11297792 | 发动机悬置软垫 | Front suspension bolster |
| 23 | A229900008929 | 发动机后悬置软垫10T74-01060 | Engine Rear Suspension Cushion |
| 24 | 60084687 | 工作灯70-24-P1 正方 | Work Lamp |
| 25 | 60149733 | 拉线传感器C-12m-R（臂头小拉线盒） | Pulling sensor |
| 26 | 60212019 | 电液换向阀LH3G1 | Electrohydraulic Reversing Valve |
| 27 | B220401001201 | 平衡阀STO517 | balanced valve |
| 28 | A229900007324 | 风扇660/86/103/10/B | Fan |
| 29 | A220400000196 | 插装阀CVI-NG25-R-H 带缓冲 | Cartridge Inserted Valve |
| 30 | 60128948 | 两位五通阀B99 4V22008 KCS017B | 2/5 valve |
| 31 | 60128950 | 电磁阀组叁阀ATC32108-3 DC24V | Electromagnetic valve group-3 Valve |
| 32 | 60220125 | 干燥器KL35AS2-55010A | Desiccator |
| 33 | A220401000615 | 差动阀KL35AS2-18010 | Differential valve |
| 34 | A220401000616 | 继动阀KL35AS1-18010 | Relay Valve |
| 35 | A229900003130 | 制动软管Q-22-700WA | Brake hose |
| 36 | A229900005108 | 制动软管Q-22-500WA | Brake Hose |
| 37 | A220401000617 | 四回路保护阀KL35BS1-34010 | Four-Way Protective Valve |
| 38 | 60147041 | 单向阀SYM5291JC.6-080 | Check Valve |
| 39 | 60230129 | 换档软轴H4550 | Geat-shifting flexshaft |
| 40 | 60230121 | 选档软轴X4700 | Gear-selecting flexshaft |
| 41 | 60167483 | 管式单向阀S15A32 海特克 | tubular Check valve |
| 42 | 60024941 | 溢流阀XCBS25-5T-06 | Relief Valve |
| 43 | 60241300 | 电磁换向阀SV08-24-0-N-24-ER | Electromagnetic Reversing Valve |
| 44 | 60184976 | 下车多路阀BLV-5SDN20/10-21 | Multi-port valve |
| 45 | B210770000087 | 测压接头SMK20-M10×1-PC | Pressure-measuring Connector |
| 46 | 60209845 | 导电环LPTS000-0330-1105-SY50 | Central conductive ring |
| 47 | 60026119 | 组合仪表SJC6110N | Combination bus instrument |
| 48 | 60034466 | 压力传感器1MPa-24V-I-M12-AMP 空气 | Pressure sensor |
| 49 | 60040048 | 翘板开关JK993-183 6.57a | Rocker Switch |
| 50 | 60060804 | 车速里程传感器A-M22 永富 | Speed odometer sensor |
| 51 | 60072876 | 压力开关1MPa-24V-650k-M16-AMP | Pressure Switch |
| 52 | 60072877 | 制动灯开关Z1/4-0.08MPa | Brake lamp switch |
| 53 | 60125384 | 电源总开关300-24-X 进口 | Master switch of power supply |
| 54 | 60147740 | 液位传感器(-)-24-D-FL | Fuel Sensor |
| 55 | 60188923 | 支腿油门开关总成HY0811-TB | Outrigger throttle switch assembly |
| 56 | A229900008853 | 电子油门踏板CUMMINS-Ⅲ-B JPS0831S（驾驶室） | Electronic throttle pedal |
| 57 | A229900008854 | 电子油门踏板CUMMINS-Ⅲ-B JP0831S（上车操作室） | Electronic throttle pedal |
| 58 | A240600000139 | 液位传感器660-N-R-C | Fuel Sensor |
| 59 | A241100000349 | 侧标志灯2-24-P0-Y 造型 | Side Marker Lamp |
| 60 | 21005650 | 翘板开关JK931-107 4.87 | Rocker Switch |
| 61 | 60120262 | 车门锁KDD-004-L | Door lock assembly of the console |
| 62 | A241200000540 | 翘板开关JK931-049 2.5 | Rocker Switch |
